Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 9-45
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
9
Modbus Commands
9.4 List of Parameters and Registers - Sorted by Daniel Registers
Address Tag Name
Data
Type
Client
Access
Description
Daniel Modicon
4005 4005
Status.NamurStates.Namu-
rAlarmCh3
Word RO
comp3's NAMUR state bit-eld (b0:F b1:M b2:S
b3:C)
4006 4006
Status.NamurStates.Namu-
rAlarmCh4
Word RO
comp4's NAMUR state bit-eld (b0:F b1:M b2:S
b3:C)
4007 4007
Status.NamurStates.Namu-
rAlarmCh5
Word RO
comp4's NAMUR state bit-eld (b0:F b1:M b2:S
b3:C)
4026 4026 Info.SensorVersion Word RO Version number of sensor rmware
4028 4028
Service.General.Identication.
CPLDVersion
Word RO Version number of CPLD rmware
4033 4033 Info.InterfaceID Word RO
ID of used Interface(1=SerProc 2=SerSvc
17=ETH1 18=ETH2)
4035 4035 Status.IO.PSAOutputState Word RO DOut state of a PSA Card
4036 4036 Status.IO.OutputState1 Word RO Output state of a XDIO Card #1
4037 4037 Status.IO.InputState1 Word RO Input state of a Digital Input Card #1
4038 4038 Status.IO.OutputState2 Word RO Output state of a XDIO Card #2
4039 4039 Status.IO.InputState2 Word RO Input state of a Digital Input Card #2
4040 4040 Status.IO.PSASHSState Word RO state of a PSA Card's SHS
8001
5001…
5002
Status.NamurStates.FailureAlarm DWord RO Namur Failure alarm biteld
8002
5003…
5004
Status.NamurStates.OffSpecAlarm DWord RO Namur Off-spec alarm biteld
8003
5005…
5006
Status.NamurStates.MaintRequAl-
arm
DWord RO Namur Maintenance Request alarm biteld
8004
5007…
5008
Status.NamurStates.FctCheckA-
larm
DWord RO Namur Function Check alarm biteld
8005
5009…
5010
Status.NamurStates.FailureActive DWord RO Namur Failure active biteld
8006
5011…
5012
Status.NamurStates.OffSpecActive DWord RO Namur Off-spec active biteld
8007
5013…
5014
Status.NamurStates.MaintRequAc-
tive
DWord RO Namur Maintenance Request active biteld
8008
5015…
5016
Status.NamurStates.FctCheckAc-
tive
DWord RO Namur Function Check active biteld
8011
5021…
5022
Service.Status.NAMUR.Failure-
Mask
DWord R/W Bitmask that disables failure sources
8012
5023…
5024
Service.Status.NAMUR.OffSpec-
Mask
DWord R/W Bitmask that disables NAMUR OffSpec sources
8013
5025…
5026
Service.Status.NAMUR.MaintMask DWord R/W
Bitmask that disables NAMUR maintenance
request sources
8014
5027…
5028
Service.Status.NAMUR.FctCheck-
Mask
DWord R/W Bitmask that disables NAMUR FctCheck sources
8015
5029…
5030
Service.Status.NAMUR.FailureMap DWord R/W Bitmask that maps cond. for failure source
8016
5031…
5032
Service.Status.NAMUR.OffSpec-
Map
DWord R/W Bitmask that maps cond. to OffSpec source
8017
5033…
5034
Service.Status.NAMUR.MaintMap DWord R/W
Bitmask that maps cond. for maintenance request
source
