6Introduction CG Drives & Automation 01-7318-01r1
1.4 Standards
The active front ends and variable speed drives described in
this instruction manual comply with the standards listed in
Table 1. For the declarations of conformity and
manufacturer’s certificate, contact your supplier for more
information or visit www.cgglobal.com or
www.emotron.com.
1.4.1 Product standard for EMC
Product standard EN(IEC)61800-3, second edition of 2004
defines the:
First Environment (Extended EMC) as environment that
includes domestic premises. It also includes establishments
directly connected without intermediate transformers to a
low voltage power supply network that supplies buildings
used for domestic purposes.
Category C2: Power Drive System (PDS) of rated
voltage<1.000 V, which is neither a plug in device nor a
movable device and, when used in the first environment, is
intended to be installed and commissioned only by a
professional.
Second environment (Standard EMC) includes all other
establishments.
Category C3: PDS of rated voltage <1.000 V, intended for
use in the second environment and not intended for use in
the first environment.
Category C4: PDS or rated voltage equal or above 1.000 V,
or rated current equal to or above 400 A, or intended for use
in complex systems in the second environment.
The active front end complies with the product standard
EN(IEC) 61800-3:2004 (Any kind of metal screened cable
may be used). The active front end is designed to meet the
requirements according to category C3.
By using the optional “Extended EMC” filter the active
front end fulfils the requirements according to category C2.
For the distributive regeneration applications, Emotron
AFG also complies with TR-61000-3-15.
15
Option position,
Communication
N=No option
D=DeviceNet
P=Profibus
S=RS232/485
M=Modbus/TCP
E= EtherCAT
A=Profinet IO 1-port
B=Profinet IO 2-port
G= EtherNet/IP 2-port
16 Software type A=Standard AFR/AFG
17 CE Approved -
18 Cooling type
L=Liquid cooled
A=Air cooled
Position Configuration
WARNING!
In a domestic environment this product may
cause radio interference, in which case it
may be necessary to take adequate
additional measures.
WARNING!
The AC drive, complying with category C3, is
not intended to be used on a low-voltage
public network which supplies domestic
premises; radio interference is expected if
used in such a network. Contact your supplier
if you need additional measures.
