122 Functional description CG Drives & Automation 01-7318-01r1
11.11 AFE Option [O00]
Main menu for AFE dedicated settings.
11.11.1 Supply parameters [O10]
Main menu for power supply parameters.
Supply Volts [O11]
Nominal supply voltage.
This parameter is important for smooth start-up. During
operation, AFE controller automatically monitors the grid
voltage.
Supply Frequency [O12]
Nominal supply frequency.
This parameter is important for smooth start-up.
During operation, AFE controller automatically monitors
the grid frequency.
Supply Current [O13]
Nominal supply current. Only used for mains supply
synchronisation and overcurrent protection.
Supply Sequence [O14]
Nominal phase sequence of supply. Supply ID run [O15]
Supply IDrun [O15]
Identification run to measure and set up supply parameters.
Supply Auto [O16]
Automatic activation of supply parameter identification
after every power-up.
Default: 400 V
Range:
380 - 460 V
480 - 690 V
Default: 50Hz
Range: 50 - 60Hz
Default: 175A
Range: 0 - AFR/AFG. Inom
O11 Supply Volts
Stp 400/690 V
O13 Supply Curr
Stp AFR/AFG.Inom
Default: Pos
Pos 0
Positive phase sequence,
i.e. L1-L2-L3
Neg 1
Negative phase sequence,
i.e. L3-L2-L1
Default: Off
Off 0
On 1 Activate the supply ID-run
Default: Off
Off 0
On 1 Activate automatic ID-run
NOTE:
Select ID-Run method in [O25].
