11.9 View Trip Log [800]
Main menu with parameters for viewing all the logged trip
data. In total the AFR/AFG saves the last 9 trips in the trip
memory. The trip memory refreshes on the FIFO principle
(First In, First Out). Every trip in the memory is logged on
the time of the Run Time [731] counter. At every trip, the
actual values of several parameter are stored and available for
troubleshooting.
11.9.1 Trip Message log [810]
Display the cause of the trip and what time that it occurred.
When a trip occurs the status menus are copied to the trip
message log. There are nine trip message logs [810]–[890].
When the tenth trip occurs the oldest trip will disappear.
For fieldbus integer value of trip message, see message table
for warnings, [722].
With four line PPU and real time clock
Every trip in the memory is logged on actual time and date.
At every trip, the actual values of several parameter are stored
and available for troubleshooting.
For fieldbus integer value of trip message, see message table
for warnings, [722].
Trip message [811] to [81P]
The information from the status menus are copied to the
trip message log when a trip occurs.
Example:
Fig. 91 shows the third trip memory menu [830]: Over
temperature trip occurred after 1396 hours and 13 minutes
in Run time.
Fig. 91 Trip 3
11.9.2 Trip Messages [820] - [890]
Same information as for menu [810].
Unit: hh:mm:ss (hours: minutes: seconds)
Range: 0h: 0m–65355h: 59m
NOTE:
Bits 0–5 used for trip message value. Bits 6–15 for
internal use.
8x0 Trip message
Unit: h: m (hours: minutes)
Range: 0h: 0m–65355h: 59m
810 Ext Trip
8x0 Trip message
Stp hh:mm:ss
810 Ext Trip
Stp 132:12:14
Trip menu Copied from Description
811 711 Q value
812 712 Cos φ
813 713 Torque
814 714 Reactive power
815 715 Electrical power
816 716 Current
817 717 Supply voltage
818 718 Frequency
819 719 DC Link voltage
81A 71A IGBT temperature
81C 721 AFR/AFG status
81D 723 Digital input status
81E 724 Digital output status
81F 725 Analogue input status 1-2
81G 726 Analogue input status 3-4
81H 727 Analogue output status 1-2
81L 731 Run Time
81M 732 Mains Time
81N 733 Energy
81O 310 Q reference
81P 72C VIO status
830 Over temp
Stp 1396h:13m
