CG Drives & Automation 01-7318-01r1 185
716 Current 31007 121/151 23EF 1007 Long, 1=0.1A EInt 113
717 Supply volt 31008 121/152 23F0 1008 Long, 1=0.1V EInt 114
718 Frequency 31009 121/153 23F1 1009 Long, 1=0.1Hz EInt 113
719 DC Voltage 31010 121/154 23F2 1010 Long, 1=0.1V EInt 114
71A IGBT Temp 31011 121/155 23F3 1011 Long, 1=0.1°C EInt 114
71B PT100 1,2,3
31012 121/156 23F4 1012 Long, 1=1°C EInt
11431013 121/157 23F5 1013 Long, 1=1°C EInt
31014 121/158 23F6 1014 Long, 1=1°C EInt
71C PT100 4,5,6
31097 121/241 2449 1097 Long, 1=1°C EInt
11431098 121/242 244A 1098 Long, 1=1°C EInt
31099 121/243 244B 1099 Long, 1=1°C EInt
720 Status 115
721 AFR Status 31015 121/159 23F7 1015 UInt UInt 115
722 Warning 31016 121/160 23F8 1016 UInt UInt 116
723 DigIn Status 31017 121/161 23F9 1017 UInt, 1=1 UInt 116
724 DigOutStatus 31018 121/162 23FA 1018
UInt, 1=1
bit 0=DigOut1,
bit 1=DigOut2
bit 8=Relay1
bit 9=Relay2
bit 10=Relay3
UInt
116
725 AnIn 1 2
31019 121/163 23FB 1019 Long, 1=1% EInt
117
31020 121/164 23FC 1020 Long, 1=1% EInt
Menu
Parameters
Default settings
Modbus
Instance/
DeviceNet No.
Profibus
slot/
index
EtherCAT
Index
(HEX)
Profinet
index
Fieldbus format
Modbus
format
Page
Remarks
To Next Page
