Emotron AFR 2.0 Series User Manual

114 Functional description CG Drives & Automation 01-7318-01r1
Supply Voltage [717]
Displays the calculated supply voltage at point of AFE
connection.
Frequency [718]
Displays the actual output frequency.
DC Link Voltage [719]
Displays the actual DC link voltage.
IGBT Temperature [71A]
Displays the actual IGBT temperature.
PT100_1_2_3 Temp [71B]
Displays the actual PT100 temperature, for PT100 board 1.
PT100_4_5_6 Temp [71C]
Displays the actual PT100 temperature, for PT100 board 2.
Unit: V
Resolution: 1 V
NOTE:
Positive value = Positive phase sequence, i.e. L1 - L2 - L3.
Negative value = Negative phase sequence, i.e. L3 - L2 - L1.
Unit: Hz
Resolution: 0.1 Hz
Unit: V
Resolution: 1 V
Unit: °C
Resolution: 0.1°C
71B PT100 1,2,3
Unit: °C
Resolution: 1°C
717 Supply Volt
Stp V
718 Frequency
Stp Hz
719 DC Voltage
Stp V
71A IGBT Temp
Stp °C
71C PT100 4,5,6
Unit: °C
Resolution: 1°C
