CG Drives & Automation 01-7318-01r1 Technical Data 163
14.2 General electrical specifications
Table 39 General electrical specifications
General
Mains voltage: VFXR46/FDUL46/VFXG46/FDUG46/AFR46/AFG46
VFXR69/FDUL69/VFXG69/FDUG69/AFR69/AFG69
Mains frequency:
Input total power factor:
Output voltage VFXR/FDUL46, VFXG/FDUG46 and
VFXR/FDUL69, VFXG/FDUG69
Output voltage AFR46/AFR69 and AFG46/AFG69
Switching
frequency:
VFXR/FDUL46, VFXG/FDUG46 and
VFXR/FDUL69, VFXG/FDUG69
AFR46/AFR69
AFG46/AFG69
Efficiency at
nominal load
VFXR/FDUL46, VFXG/FDUG46 and
VFXR/FDUL69, VFXG/FDUG69
AFR46/AFR69 and AFG46/AFG69
Harmonics to supply, THDI
380 - 460 V +10%/-15%
480 - 690 V +10%/-15%
48 to 52Hz and 58 to 62Hz
1.0
(0 - 1.2) * Mains supply voltage (V AC)
(1.0 - 1.2) * * Mains supply voltage (V DC)
3 kHz (adjustable 1.5 - 6 kHz, FDUL only)
3 kHz
3150 *Main frequency/50
97%
98%
< 5%
Control signal inputs:
Analogue (differential)
Analogue Voltage/current:
Max. input voltage:
Input impedance:
Resolution:
Hardware accuracy:
Non-linearity
0-±10 V/0-20 mA via switch
+30 V/30 mA
20 k
Ω (voltage)
250
Ω (current)
11 bits + sign
1% type + 1½ LSB fsd
1½ LSB
Digital:
Input voltage:
Max. input voltage:
Input impedance:
Signal delay:
High: >9 V DC, Low: <4 V DC
+30 V DC
<3.3 V
DC
: 4.7 kΩ
≥3.3 V
DC
: 3.6 kΩ
≤
8 ms
Control signal outputs
Analogue
Output voltage/current:
Max. output voltage:
Short-circuit current (
∞):
Output impedance:
Resolution:
Maximum load impedance for current
Hardware accuracy:
Offset:
Non-linearity:
0-10 V/0-20 mA via software setting
+15 V @5 mA cont.
+15 mA (voltage), +140 mA (current)
10
Ω (voltage)
10 bit
500
Ω
1.9% type fsd (voltage), 2.4% type fsd (current)
3 LSB
2 LSB
Digital
Output voltage:
Shortcircuit current(∞):
High: >20 V DC @50 mA, >23 V DC
open
Low: <1 V DC @50 mA
100 mA max (together with +24 V DC)
Relays
Contacts 0.1 – 2 A/U
max
250 VAC or 42 V
DC
References
+10 V DC
-10 V DC
+24 V DC
+10 V DC @10 mA Short-circuit current +30 mA max
-10 V DC @10 mA
+24 V DC Short-circuit current +100 mA max (together
with Digital Outputs)
