162 Technical Data CG Drives & Automation 01-7318-01r1
14.1.4 Emotron AFG
Assembled in IP54 cabinet including main switch + main contactor or motorized circuit breaker.
*) Available for a limited time and as long as drive temperature permits.
**) Power given is at 0.9 displacement power factor. At unity power displacement factor, higher output power can be achieved
accordingly.
**) For 460V AC supply, same output power available with reduced current capability.
Assembled in IP54 cabinet including main switch + main contactor or motorized circuit breaker.
*) Available for a limited time and as long as drive temperature permits.
**) Power given is at 0.9 displacement power factor. At unity power displacement factor, higher output power can be achieved
accordingly.
Ta b l e 3 7 A F G 4 6 Ty p i c a l o u t p u t D C power at mains voltage 400V.
Model
Max input current
Imax [A]*
@400 V AC
Normal duty 120%,
1 min every 10 min
Frame
(IP20 stacked)
Dimensions
Height=2.250 mm
(88.6 in)
Depth=600 mm (23.6 in)
Width
mm (inches)
Rated
input current
Inom [A]
@400 V AC
Output power
@400 V AC
@ 0.9 DPF [kW]**
AFG46-109 131 109 68 E (single) 600 (23.6)
AFG46-175 210 175 110 E (single) 600 (23.6)
AFG46-250 300 250 156 F (single) 600 (23.6)
AFG46-350 420 350 220 G 800 (31.5)
AFG46-500 600 500 312 H 1000 (39.4)
AFG46-750 900 750 468 I 1200 (47.2)
AFG46-1K0 1200 1000 624 J 1800 (70.9)
AFG46-1K5 1800 1500 936 K 2400 (94.5)
Table 38 AFG69 Typical output power at mains voltage 690 V.
Model
Max input current
Imax [A]* @690 V
AC
Normal duty 120%,
1 min every 10 min
Frame
(IP20 stacked)
Dimensions
Height=2,250 mm
(88.6 in)
Depth=600 mm (23.6 in)
Width
mm (inches)
Rated
input current
Inom [A]
@690 V AC
Output
power
@690 V AC
[kW] **
AFG69-146 175 146 156 F69 (single) 600 (23.6)
AFG69-292 350 292 312 H69 1000 (39.4)
AFG69-438 525 438 468 I69 1200 (47.2)
AFG69-584 700 584 624 J69 1800 (70.9)
AFG69-876 1050 876 936 K69 2400 (94.5)
