CG Drives & Automation 01-7318-01r1 Functional description 113
11.8 View Operation/Status
[700]
Menu with parameters for viewing all actual operational
data, such as frequency, torque, power, etc.
11.8.1 Operation [710]
Reactive power value [711]
Displays the actual controlled reactive power value in % of
nominal power.
Displacement power factor [712]
Displays the calculated displacement power factor at AFR/
AFG terminals. Power factor calculation is given in section
7.14.
Torque [713]
Displays the virtual torque in % of nominal power and
in W.
Reactive power [714]
Displays the actual reactive power.
Electrical Power [715]
Displays the actual electrical output power.
Current [716]
Displays the actual output current.
NOTE:
Positive value - Capacitive or leading.
Negative value - Inductive or lagging.
Unit %
Resolution 1%
NOTE:
Positive value - Over excited power factor.
Negative value - Under excited power factor.
NOTE:
Sign in displacement power factor is just to differentiate
between excited and under excited power factor.
Range: -1 to 1
Resolution: 0.001
NOTE:
Positive value - Generating.
Negative value - Motoring.
Unit: W
Resolution: 1 W
NOTE:
Positive value - Over excited or capacitive.
Negative value - Under excited or Inductive.
Unit: VA
Resolution: 1VA
NOTE:
Positive value - Generating.
Negative value - Motoring.
Unit: W
Resolution: 1 W
Unit: A
Resolution: 0.1 A
