CG Drives & Automation 01-7318-01r1 Technical Data 165
14.5 Control signals
Ta b l e 4 2
Terminal X1 Name: Function (Default): Signal: Type:
1 +10 V +10 VDC Supply voltage +10 V DC, max 10 mA output
2 AnIn1 Process reference
0 -10 V DC or 0/4–20 mA
bipolar: -10 - +10 V DC or -20 - +20 mA
analogue input
3 AnIn2
AFR: Off
AFG: U(L1)
0 -10 V DC or 0/4–20 mA
bipolar: -10 - +10 V DC or -20 - +20 mA
analogue input
4 AnIn3
AFR: Off
AFG: U(L2)
0 -10 V DC or 0/4–20 mA
bipolar: -10 - +10 V DC or -20 - +20 mA
analogue input
5 AnIn4
AFR: Off
AFG: U(L3)
0 -10V DC or 0/4–20 mA
bipolar: -10 - +10 V DC or -20 - +20 mA
analogue input
6 -10 V -10VDC Supply voltage -10 V DC, max 10 mA output
7 Common Signal ground 0V output
8 DigIn 1 RunL (Fixed) 0-8/24 V DC digital input
9 DigIn 2 RunR (Fixed) 0-8/24 V DC digital input
10 DigIn 3 Enable 0-8/24 V DC digital input
11 +24 V +24VDC Supply voltage +24 V DC, 100 mA output
12 Common Signal ground 0 V output
13 AnOut 1 0 ±10 V DC or 0/4– +20 mA analogue output
14 AnOut 2 0 to max torque 0 ±10 V DC or 0/4– +20 mA analogue output
15 Common Signal ground 0 V output
16 DigIn 4 Off 0-8/24 V DC digital input
17 DigIn 5 Off 0-8/24 V DC digital input
18 DigIn 6 Off 0-8/24 V DC digital input
19 DigIn 7 Off 0-8/24 V DC digital input
20 DigOut 1
LY, Active when AFE is not running or
Dc-link voltage has not reached
reference value.
24 V
DC
, 100 mA digital output
21 DigOut 2 LZ (trip pulse of 1s) 24 V
DC
, 100 mA digital output
22 DigIn 8 RESET 0-8/24 VDC digital input
Terminal X2
31 N/C 1
Relay 1 output
Dedicated for Charge Relay contactor
K2.
potential free change over
0.1 – 2 A/U
max
250 V AC or 42 V DC
relay output32 COM 1
33 N/O 1
41 N/C 2
Relay 2 Output
LY, Active when AFE is not running or
Dc-link voltage has not reached
reference value.
potential free change over
0.1 – 2 A/U
max
250 V AC or 42 V DC
relay output
42 COM 2
43 N/O 2
Terminal X3
51 COM 3
Relay 3 Output,
Dedicated for Main Contactor K1
potential free change over
0.1 – 2 A/U
max
250 V AC or 42 V DC
relay output
52 N/O 3
