Emotron AFR 2.0 Series User Manual

CG Drives & Automation 01-7318-01r1 Functional description 71
11.3 Menus
11.3.1 Resolution of settings
The resolution for all range settings described in this chapter
is 3 significant digits. Table 19 shows the resolutions for 3
significant digits.
11.3.2 1st Line [110]
Sets the content of the upper row in the menu [100]
Preferred View
.
11.3.3 2nd Line [120]
Sets the content of the lower row in the menu [100]
Preferred View. Same selection as in menu [110].
11.3.4 3rd Line [130]
Sets the content of the third line in the menu
“[100] Preferred View”. Same selection as in menu [110].
11.3.5 4th Line [140]
Sets the content of the fourth line in the menu
“[100] Preferred View”. Same selection as in menu [110].
11.3.6 5th Line [150]
Sets the content of the fifth line in the menu
“[100] Preferred View”. Same selection as in menu [110].
11.3.7 6th Line [160]
Sets the content of the sixth line in the menu
“[100] Preferred View”. Same selection as in menu [110].
Ta b l e 1 9
3 Digit Resolution
0.01-9.99 0.01
10.0-99.9 0.1
100-999 1
1000-9990 10
10000-99900 100
Default: Current
Dependent on menu
Process Val 0 Process value (Q)
Torque 2 Torque
Process Ref 3 Process reference
React Power 4 Reactive power
El Power 5 Electrical power
Current 6 Current
Output volt 7 Output voltage
Frequency 8 Frequency
DC Voltage 9 DC voltage
IGBT Temp 10 IGBT temperature
AFR/AFG
Status
12 AFR/AFG status
Run Time 13 Run Time
Energy 14 Energy
Mains Time 15 Mains time
110 1st Line
Stp Current
Default: Torque
NOTE: Following menus [130] to [170] are only valid
for the control panel with 4-line display.
Default: Frequency
Default: AFR/AFG Status
Default: DC Voltage
Default: IGBT Temp
120 2nd Line
Stp Torque
130 3rd Line
Stp Frequency
140 4th Line
Stp AFR/AFG Status
150 5th Line
Stp DC Voltage
160 6th Line
Stp IGBT Temp
