CG Drives & Automation 01-7318-01r1 167
15. Menu List and communication information
This is a list of the menu parameters and their factory settings, along with communication settings for the most important bus formats.
Complete lists with communication data and parameter set information could be downloaded from www.cgglobal.com or www.emotron.com.
Menu
Parameters
Default settings
Modbus
Instance/
DeviceNet No.
Profibus
slot/
index
EtherCAT
Index
(HEX)
Profinet
index
Fieldbus format
Modbus
format
Page
Remarks
100 Preferred View 69
110 1st Line Current 43001 168/160 4BB9 19385 UInt UInt 71
120 2nd Line Torque 43002 168/161 4BBA 19386 UInt UInt 71
130 3rd Line Frequency 43003 168/162 4BBB 19387 UInt UInt 71
140 4th Line AFR Status 43004 168/163 4BBC 19388 UInt UInt 71
150 5th Line DC Voltage 43005 168/164 4BBD 19389 UInt UInt 71
160 6th Line IGBT Temp 43006 168/165 4BBE 19390 UInt UInt 71
170 View mode Normal 100 43007 168/166 4BBF 19391 UInt UInt 72
200 Main Setup 72
210 Operation 72
211 Language English 43011 168/170 4BC3 19395 UInt UInt 72
214 Ref Control Keyboard 43014 168/173 4BC6 19398 UInt UInt 72
215 Run/Stp Ctrl Keyboard 43015 168/174 4BC7 19399 UInt UInt 73
216 Reset Ctrl Remote+Keyb 43016 168/175 4BC8 19400 UInt UInt 73
217 Local/Rem 73
2171 LocRefCtrl Standard 43009 168/168 4BC1 19393 UInt UInt 73
