120 Functional description CG Drives & Automation 01-7318-01r1
11.9.3 Reset Trip Log [8A0]
Resets the content of the 10 trip memories.
11.10 System Data [900]
Main menu for viewing all the AFR/AFG system data.
11.10.1 AFR/AFG Data [920]
AFR/AFG Type [921]
Shows the AFR/AFG type according to the type number.
The options are indicated on the type plate of the AFR/
AFG.
Fig. 92 Example of type
Examples:
AFR/AFG46-175 suited for 380-460 V mains supply and a
rated input current of 175 A.
Software [922]
Shows the software version number of the AFR/AFG.
Fig. 93 gives an example of the version number.
Fig. 93 Example of software version
V 4.45 = Software version
- 97.10 = option version, is only visible and valid for special
software, type OEM adapted software.
97 = (major) special software variant number
10 = (minor) revision of this special software
Default: No
No 0
Yes 1
NOTE: After the reset the setting goes automatically
back to “NO”. The message “OK” is displayed for 2 sec.
Table 26 Information for Modbus and Profibus number,
software version
Bit Description
7–0 minor version
13–8 major version
15–14
release type
00: V, release version
01: P, pre-release version
10:
β, Beta version
11: α, Alpha version
Table 27 Information for Modbus and Profibus number,
option version
Bit Description
7–0 minor option version
15–8 major option version
921 AFR/AFG2.0
Stp AFR/AFG46-175
922 Software
Stp V4.45-97.10
