1.5 Dismantling and scrapping
The enclosures of the drives are made from recyclable
material as aluminum, iron and plastic. Each drive contains
a number of components demanding special treatment, for
example electrolytic capacitors. The circuit boards contain
small amounts of tin and lead. Any local or national
regulations in force for the disposal and recycling of these
materials must be complied with.
1.5.1 Disposal of old electrical and
electronic equipment
This information is applicable in the European Union and
other European countries with separate collection systems.
This symbol on the product or on its packaging indicates
that this product shall be taken to the applicable collection
point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly,
you will help prevent potentially negative consequences for
the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product.
The recycling of materials will help to conserve natural
resources. For more detailed information about recycling
this product, please contact the local distributor of the
product.
1.6 Glossary
1.6.1 Abbreviations and symbols
In this manual the following abbreviations are used:
Table 2 Abbreviations
Abbreviation/
symbol
Description
AC drive Frequency converter
AFE
Active front end (electronics, control board
and power module part)
AFG
Active front end for generation with full/
advanced grid code functionality
AFR
Low harmonic/regenerative front end with no
grid support
AID
Anti-Islanding detection
BLE Blue tooth
Comm
Command sourced from serial communication
CP
Control panel, the programming and
presentation unit on the AC drive
DFE Diode front end
DPF
Displacement power factor
EInt Communication format
FDUG
Complete power drive train, including AFG
and VSI (FDU)
FDUL
Low harmonic FDU drive, including AFR and
VSI (FDU)
FRT
Fault-ride through
GC
Gride Code
Int Communication format (Integer)
Keyb Command sourced from keyboard
LCL-filter
Inductance - Capacitance - Inductance
type filter
LFSM-O
Limited frequency sensitivity mode -
over-frequency
Long Communication format (4 byte integer)
OFRT
Over-frequency ride-through
OVRT
Over-voltage ride-through
PLL Phase locked loop
ROCOF Rate of change of frequency
SVMB
Supply voltage measurement board
THD Total harmonic distortion
UFRT
Under-frequency ride-through
UInt Communication format (Unsigned integer)
UVRT
Under-voltage ride-through
