14. Technical Data
14.1 Electrical and mechanical specifications related to model
14.1.1 Emotron VFXR/FDUL
Assembled in IP54 cabinet including main switch + main contactor or motorized circuit breaker.
*) Available for a limited time and as long as drive temperature permits.
Table 33 VFXR/FDUL typical motor power at mains voltage 400 V and 460 V (refer also to the instruction manual for Emotron
VFX/FDU)
VFXR/FDUL
Model
Max
output
current
Imax
[A]*
Normal duty 120%,
1 min every 10 min
Heavy duty 150%,
1 min every 10 min
Frame
Dimensions
Height=2,250 mm
(88.6 in)
Depth=600 mm
(23.6 in)
Width
mm (inches)
Weight
kg (lbs) AFR model
Rated
current
Inom
[A]
Power
@400 V
[kW]
Power
@460 V
[HP]
Rated
current
Inom
[A]
Power
@400 V
[kW]
Power
@460 V
[HP]
46-109 131 109 55 75 87 45 60 E46+E=G 800 (31.5) 380 (836) AFR46-175
46-146 175 146 75 100 117 55 75 E46+E=G 800 (31.5) 400 (880) AFR46-175
46-175 210 175 90 125 140 75 100 E46+E=G 900 (35.4) 480 (1056) AFR46-175
46-210 252 210 110 150 168 90 125 F46+F=H 900 (35.4) 500 (1100) AFR46-250
46-250 300 250 132 200 200 110 150 F46+F=H 900 (35.4) 500 (1100) AFR46-250
46-300 360 300 160 250 240 132 200 F46+H=I 1300 (51.2) 700 (1540) AFR46-250
46-375 450 375 200 300 300 160 250 G46 +G 1500 (59.1) 750 (1650) AFR46-375
46-430 516 430 220 350 344 200 250 G46+H 1500 (59.1) 830 (1826) AFR46-375
46-500 600 500 250 400 400 220 350 H46+H 1500 (59.1) 880 (1936) AFR46-500
46-600 720 600 315 500 480 250 400 H46+I 1900 (74.8) 1040 (2288) AFR46-500
46-650 780 650 355 550 520 315 400 I46+I 2200 (86.6) 1210 (2662) AFR46-750
46-750 900 750 400 600 600 355 500 I46+I 2200 (86.6) 1210 (2662) AFR46-750
46-860 1032 860 450 700 688 400 550 I46+J 2500 (98.4) 1370 (3014) AFR46-750
46-1K0 1200 1000 560 800 800 450 650 J46+J 3000 (118.1) 1600 (3527) AFR46-1K0
46-1K2 1440 1200 630 900 960 500 750 J46+KA 3300 (129.9) 1700 (3748) AFR46-1K0
46-1K5 1800 1500 800 1250 1200 630 1000 K46+K 4500 (177.2) 2250 (4960) AFR46-1K5
46-1K75 2100 1750 900 1500 1400 800 1200 K46+L On request AFR46-1K5
