160 Technical Data CG Drives & Automation 01-7318-01r1
Assembled in IP54 cabinet including main switch + main contactor or motorized circuit breaker.
*) Available for a limited time and as long as drive temperature permits.
Table 34 VFXR/FDUL typical motor power at mains voltage 575 V and 690 V
VFXR/
FDUL
Model
Max
output
current
Imax
[A]*
Normal duty 120%,
1 min every 10 min
Heavy duty 150%,
1 min every 10 min
Frame
Dimensions
Height=2,250 mm
(88.6 in)
Depth=600 mm
(23.6 in)
Width
mm (inches)
Weight
kg (lbs) AFR model
Rated
current
Inom
[A]
Power
@690 V
[kW]
Power
@575 V
[HP]
Rated
current
Inom
[A]
Power
@690 V
[kW]
Power
@575 V
[HP]
69-109 131 109 110 100 87 90 75 F69+F69=H69 800 (31.5) 410 (902) AFR69-175
69-146 175 146 132 125 117 110 100 F69+F69=H69 800 (31.5) 430 (946) AFR69-175
69-185 222 185 160 150 148 132 125 F69+F69=H69 900 (35.4) 540 (1188) AFR69-175
69-250 300 250 250 250 200 200 200 H69+H69 1,800 (70.9) 870 (1914) AFR69-350
69-300 360 300 315 300 240 250 250 H69+H69 1,800 (70.9) 870 (1914) AFR69-350
69-375 450 375 355 350 300 315 300 H69+H69 1,800 (70.9) 910 (2002) AFR69-350
69-430 516 430 450 400 344 355 350 I69+I69 2,800 (110.2) 1350 (2970) AFR69-525
69-560 672 560 560 600 448 450 400 I69+I69 2,800 (110.2) 1390 (3058) AFR69-525
69-749 900 750 710 750 600 600 600 J69+J69 On request AFR69-700
69-995 1200 1000 1000 1000 800 800 850 K69+KA69 On request AFR69-1K05
69-1K12 1344 1120 1100 1200 896 900 950 K69+K69 On request AFR69-1K05
