Emotron AFR 2.0 Series User Manual

186 CG Drives & Automation 01-7318-01r1
726 AnIn 3 4
31021 121/165 23FD 1021 Long, 1=1% EInt
117
31022 121/166 23FE 1022 Long, 1=1% EInt
727 AnOut1 2
31023 121/167 23FF 1023 Long, 1=1% EInt
117
31024 121/168 2400 1024 Long, 1=1% EInt
728 IO B1 31025 121/169 2401 1025
UInt, 1=1
bit 0=DigIn1
bit 1=DigIn2
bit 2=DigIn3
bit 8=Relay1
bit 9=Relay2
bit 10=Relay3
UInt
117
729 IO B2 31026 121/170 2402 1026
UInt, 1=1
bit 0=DigIn1
bit 1=DigIn2
bit 2=DigIn3
bit 8=Relay1
bit 9=Relay2
bit 10=Relay3
UInt
117
72A IO B3 31027 121/171 2403 1027
UInt, 1=1
bit 0=DigIn1
bit 1=DigIn2
bit 2=DigIn3
bit 8=Relay1
bit 9=Relay2
bit 10=Relay3
UInt
117
72C VIO Status 30181 118/90 20B5 181 UInt UInt 117
730 Stored Val 118
Menu
Parameters
Default settings
Modbus
Instance/
DeviceNet No.
Profibus
slot/
index
EtherCAT
Index
(HEX)
Profinet
index
Fieldbus format
Modbus
format
Page Remarks
