Warning [722]
Display the actual or last warning condition. A warning
occurs if the AC drive is close to a trip condition but still in
operation. During a warning condition the red trip LED
will start to blink as long as the warning is active.
The active warning message is displayed in menu [722]. If
no warning is active the message “No Error” is displayed.
The following warnings are possible:
Digital Input Status [723]
Indicates the status of the digital inputs. See Fig. 86.
1DigIn 1
2DigIn 2
3DigIn 3
4DigIn 4
5DigIn 5
6DigIn 6
7DigIn 7
8DigIn 8
The positions one to eight (read from left to right) indicate
the status of the associated input:
1High
0Low
The example in Fig. 86 indicates that DigIn 1,
DigIn 3 and DigIn 6 are active at this moment.
Fig. 86 Digital input status example
Digital Output Status [724]
Indicates the status of the digital outputs and relays.
See Fig. 87.
RE indicate the status of the relays on position:
1Relay1
2Relay2
3Relay3
DO indicate the status of the digital outputs on position:
1DigOut1
2DigOut2
The status of the associated output is shown.
1High
0Low
The example in Fig. 87 indicates that DigOut1 is active and
Digital Out 2 is not active. Relay 1 is active, relay 2 and 3
are not active.
Fig. 87 Digital output status example
Communi-
cation
integer
value
Warning message
0No Error
2PTC
5Ext trip
6 Mon MaxAlarm
7 Mon MinAlarm
8 Comm error
9PT100
12 Ext Mot Temp
13 LC Level
15 Option
16 Over temp
17 Over curr F
18 Over volt D
19 Over volt G
20 Over volt M
21 Over speed
22 Under voltage
23 Power fault
24 Desat
25 DClink error
26 Int error
27 Ovolt m cut
28 Over voltage
29 Start denied
30 Not used
723 DigIn Status
Stp 1010 0100
724 DigOutStatus
Stp RE 100 DO 10
