6Introduction Emotron AB 01-4429-01r2
1.4 Standards
The variable speed drives described in this instruction man-
ual comply with the standards listed in Table 1. For the dec-
larations of conformity and manufacturer’s certificate,
contact your supplier for more information or visit
www.emotron.com.
1.4.1Product standard for EMC
Product standard EN(IEC)61800-3, second edition of 2004
defines the:
First Environment (Extended EMC) as environment that
includes domestic premises. It also includes establishments
directly connected without intermediate transformers to a
low voltage power supply network that supplies buildings
used for domestic purposes.
Category C2: Power Drive System (PDS) of rated volt-
age<1.000 V, which is neither a plug in device nor a movable
device and, when used in the first environment, is intended
to be installed and commissioned only by a professional.
Second environment (Standard EMC) includes all other
establishments.
Category C3: PDS of rated voltage <1.000 V, intended for
use in the second environment and not intended for use in
the first environment.
Category C4: PDS or rated voltage equal or above 1.000 V,
or rated current equal to or above 400 A, or intended for use
in complex systems in the second environment.
The variable speed drive complies with the product standard
EN(IEC) 61800-3:2004 (Any kind of metal screened cable
may be used). The standard variable speed drive is designed
to meet the requirements according to category C3.
By using the optional “Extended EMC” filter the VSD ful-
fils requirements according to category C2,
44Protection class
20=IP20
54=IP54
5 5 Control panel
–=Blank panel
C=Standard panel
6 6 EMC option
E=Standard EMC
(Category C3)
F=Extended EMC
(Category C2)
I=IT-Net
77
Brake chopper
option
–=No chopper
B=Chopper built in
D=DC+/- interface
88
Stand-by power sup-
ply option
–=No SBS
S=SBS included
-9
Safe stop option
(Not valid for
003-046)
–=No safe stop
T=Safe stop incl.
(Only 090-1500)
910Brand label A=Emotron
10 -
Painted VSD
(Only valid for
003-046)
A=Standard paint
B=White paint
RAL9010
11 11
Coated boards,
option
A=Standard
boards
V=Coated boards
12 12 Option position 1 N=No option
C=Crane I/O
E=Encoder
P=PTC/PT100
I=Extended I/O
S=Safe Stop (only
003-046)
13 13 Option position 2
14 14 Option position 3
15 15
Option position, com-
munication
N=No option
D=DeviceNet
P=Profibus
S=RS232/485
M=Modbus/TCP
16 16 Software type A=Standard
17 17
Motor PTC. (Only
valid for 003-046)
N=No option
P=PTC
18 18
Gland kit.
(Only valid for 003-
046)
–=Glands not
included
G=Gland kit
included
Position
for 003-
046
Position
for 060-
1500
Configuration
WARNING: In a domestic environment this
product may cause radio interference, in
which case it may be necessary to take
adequate additional measures.
WARNING: The standard VSD, complying with
category C3, is not intended to be used on a
low-voltage public network which supplies
domestic premises; radio interference is
expected if used in such a network. Contact
your supplier if you need additional
measures.
CAUTION: In order to comply fully with the
standards stated in the Manufacturer’s
Declaration ANNEX IIB, the installation
instructions detailed in this instruction
manual must be followed to the letter.
