Emotron VFX 2.0 User Manual

Emotron AB 01-4429-01r2 Technical Data 163
14.2 General electrical specifications
Table 43 General electrical specifications
General
Mains voltage: VFX40
VFX48
VFX50/52
VFX69
Mains frequency:
Input power factor:
Output voltage:
Output frequency:
Output switching frequency:
Efficiency at nominal load:
230-415V +10%/-15% (-10% at 230 V)
230-480V +10%/-15% (-10% at 230 V)
440-525V +10%/-15%
500-690V +10%/-15%
45 to 65 Hz
0.95
0–Mains supply voltage:
0–400 Hz
3 kHz
97% for models 003 to 018
98% for models 026 to 046
97.5% for models 060 to 073
98% for models 090 to 1500
Control signal inputs:
Analogue (differential)
Analogue Voltage/current:
Max. input voltage:
Input impedance:
Resolution:
Hardware accuracy:
Non-linearity
0-±10 V/0-20 mA via switch
+30 V/30 mA
20 k
Ω (voltage)
250
Ω (current)
11 bits + sign
1% type + 1 ½ LSB fsd
1½ LSB
Digital:
Input voltage:
Max. input voltage:
Input impedance:
Signal delay:
High: >9 VDC, Low: <4 VDC
+30 VDC
<3.3 VDC: 4.7 k
Ω
≥3.3 VDC: 3.6 kΩ
≤
8 ms
Control signal outputs
Analogue
Output voltage/current:
Max. output voltage:
Short-circuit current (
∞):
Output impedance:
Resolution:
Maximum load impedance for current
Hardware accuracy:
Offset:
Non-linearity:
0-10 V/0-20 mA via software setting
+15 V @5 mA cont.
+15 mA (voltage), +140 mA (current)
10
Ω (voltage)
10 bit
500
Ω
1.9% type fsd (voltage), 2.4% type fsd (current)
3 LSB
2 LSB
Digital
Output voltage:
Shortcircuit current(
∞):
High: >20 VDC @50 mA, >23 VDC open
Low: <1 VDC @50 mA
100 mA max (together with +24 VDC)
Relays
Contacts 0.1 – 2 A/U
max
250 VAC or 42 VDC
References
+10VDC
-10VDC
+24VDC
+10 V
DC
@10 mA Short-circuit current +30 mA max
-10 V
DC
@10 mA
+24 V
DC
Short-circuit current +100 mA max (together with Digital Outputs)
