Emotron VFX 2.0 User Manual

162 Technical Data Emotron AB 01-4429-01r2
* Available during limited time and as long as allowed by drive temperature.
* Available during limited time and as long as allowed by drive temperature.
Table 41 Typical motor power at mains voltage 575 V
Model
Max. output
current [A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
Power @575V [hp] Rated current [A] Power @575V [hp] Rated current [A]
VFX69-090 108 75 90 60 72
F69
VFX69-109 131 100 109 75 87
VFX69-146 175 125 146 100 117
VFX69-175 210 150 175 125 140
VFX69-210 252 200 210 150 168
H69
VFX69-250 300 250 250 200 200
VFX69-300 360 300 300 250 240
VFX69-375 450 350 375 300 300
VFX69-430 516 400 430 350 344
I69
VFX69-500 600 500 500 400 400
VFX69-600 720 600 600 500 480
J69
VFX69-650 780 650 650 550 520
VFX69-750 900 750 750 600 600
K69VFX69-860 1032 850 860 700 688
VFX69-1000 1200 1000 1000 850 800
Table 42 Typical motor power at mains voltage 690 V
Model
Max. output
current [A]*
Normal duty
(120%, 1 min every 10 min)
Heavy duty
(150%, 1 min every 10 min)
Frame size
Power @690V [kW] Rated current [A] Power @690V [kW] Rated current [A]
VFX69-090 108 90 90 75 72
F69
VFX69-109 131 110 109 90 87
VFX69-146 175 132 146 110 117
VFX69-175 210 160 175 132 140
VFX69-210 252 200 210 160 168
H69
VFX69-250 300 250 250 200 200
VFX69-300 360 315 300 250 240
VFX69-375 450 355 375 315 300
VFX69-430 516 450 430 315 344
I69
VFX69-500 600 500 500 355 400
VFX69-600 720 600 600 450 480
J69
VFX69-650 780 630 650 500 520
VFX69-750 900 710 750 600 600
K69
VFX69-860 1032 800 860 650 688
VFX69-900 1080 900 900 710 720
VFX69-1000 1200 1000 1000 800 800
