11.1.2 2nd Line [120]
Sets the content of the lower row in the menu [100] Pre-
ferred View. Same selection as in menu [110].
11.2 Main Setup [200]
The Main Setup menu contains the most important settings
to get the VSD operational and set up for the application. It
includes different sub menus concerning the control of the
unit, motor data and protection, utilities and automatic
resetting of faults. This menu will instantaneously be
adapted to build in options and show the required settings.
11.2.1 Operation [210]
Selections concerning the used motor, VSD mode, control
signals and serial communication are described in this sub-
menu and is used to set the VSD up for the application.
Language [211]
Select the language used on the LC Display. Once the lan-
guage is set, this selection will not be affected by the Load
Default command.
Communication information
Select Motor [212]
This menu is used if you have more than one motor in your
application. Select the motor to define. It is possible to
define up to four different motors, M1 to M4, in the VSD.
Communication information
Drive Mode [213]
This menu is used to set the control mode for the motor.
Settings for the reference signals and read-outs is made in
menu Process source, [321].
• Speed Mode offers an accurate control of the motor
speed independently of the load. The Speed mode also
increases the accuracy of the different analogue output
signals that are related to the motor speed. Speed mode
can also be used if several motors of same type and size
are connected in parallel. Requires all motors to be
mechanically connected to the load.
• Torque Mode can be selected for applications where the
motor shaft torque needs to be controlled independently
of the speed.
• V/Hz Mode (output speed [712] in rpm) is used when
several motors in parallel of different type or size are con-
nected or if parallel motors are not mechanically con-
nected to the load.
Default: Torque
Default: English
English 0 English selected
Svenska 1 Swedish selected
Nederlands 2 Dutch selected
Deutsch 3 German selected
Français 4 French selected
Español 5 Spanish selected
Руccкий 6Russian selected
Italiano 7 Italian selected
Česky 8 Czech selected
Modbus Instance no/DeviceNet no: 43011
Profibus slot/index 168/170
Fieldbus format UInt
Modbus format UInt
Default: M1
M1 0
Motor Data is connected to selected
motor.
M2 1
M3 2
M4 3
Modbus Instance no/DeviceNet no: 43012
Profibus slot/index 168/171
Fieldbus format UInt
Modbus format UInt
