Emotron VFX 2.0 User Manual

174 Menu List Emotron AB 01-4429-01r2
266A FB Signal 10
266B FB Signal 11
266C FB Signal 12
266D FB Signal 13
266E FB Signal 14
266F FB Signal 15
266G FB Signal 16
269 FB Status
300 Process
310 Set/View ref
320 Proc Setting
321 Proc Source Speed
322 Proc Unit Off
323 User Unit 0
324 Process Min 0
325 Process Max 0
326 Ratio Linear
327 F(Val) PrMin Min
328 F(Val) PrMax Max
330 Start/Stop
331 Acc Time 10.00s
332 Dec Time 10.00s
333 Acc MotPot 16.00s
334 Dec MotPot 16.00s
335 Acc>Min Spd 10.00s
336 Dec<Min Spd 10.00s
337 Acc Rmp Linear
338 Dec Rmp Linear
339 Start Mode Normal DC
33A Spinstart Off
33B Stop Mode Decel
33C Brk Release 0.00s
33D Release Spd 0rpm
33E Brk Engage 0.00s
33F Brk Wait 0.00s
33G Vector Brake Off
340 Speed
341 Min Speed 0rpm
342 Stp<MinSpd Off
343 Max Speed 1500rpm
344 SkipSpd 1 Lo 0rpm
345 SkipSpd 1 Hi 0rpm
346 SkipSpd 2 Lo 0rpm
347 SkipSpd 2 Hi 0rpm
348 Jog Speed 50rpm
350 Torques
351 Max Torque 120%
352 IxR Comp Automatic
353 IxR CompUsr 0%
354 Flux optim Off
360 Preset Ref
361 Motor Pot Non Volatile
362 Preset Ref 1 0 rpm
363 Preset Ref 2 250 rpm
DEFAULT CUSTOM
364 Preset Ref 3 500 rpm
365 Preset Ref 4 750 rpm
366 Preset Ref 5 1000 rpm
367 Preset Ref 6 1250 rpm
368 Preset Ref 7 1500 rpm
369 Keyb Ref Normal
370 Spd Ctrl PI
371 Spd PI Auto Off
372 Spd P Gain
373 Spd I Time
380 ProcCtrlPID
381 PID Control Off
383 PID P Gain 1.0
384 PID I Time 1.00s
385 PID D Time 0.00s
386 PID<MinSpd Off
387 PID Act Marg 0
388 PID Stdy Tst Off
389 PID Stdy Mar 0
390 Pump/Fan Ctrl
391 Pump enable Off
392 No of Drives 2
393 Select Drive Sequence
394 Change Cond Both
395 Change Timer 50h
396 Drives on Ch 0
397 Upper Band 10%
398 Lower Band 10%
399 Start Delay 0s
39A Stop Delay 0s
39B Upp Band Lim 0%
39C Low Band Lim 0%
39D Settle Start 0s
39E TransS Start 60%
39F Settle Stop 0s
39G TransS Stop 60%
39H Run Time 1 00:00:00
39H1 Rst Run Tm1 No
39I Run Time 2 00:00:00
39I1 Rst Run Tm2 No
39J Run Time 3 00:00:00
39J1 Rst Run Tm3 No
39K Run Time 4 00:00:00
39K1 Rst Run Tm4 No
39L Run Time05 00:00:00
39L1 Rst Run Tm5 No
39M Run Time 6 00:00:00
39M1 Rst Run Tm6 No
39N Pump 123456
3A0 Crane Option
3A1 Crane enable Off
3A2 Control 4-Speed
3A3 Crane Relay 1 Brake
3A4 Crane Relay 2 Brake
DEFAULT CUSTOM
