Emotron AB 01-4429-01r2 Operation via the Control Panel 47
500 Inputs/Outputs and Virtual
Connections
All settings for inputs and outputs are entered here.
600 Logical Functions and Timers
All settings for conditional signal are entered here.
700 View Operation and Status
Viewing all the operational data like frequency, load, power,
current, etc.
800 View Trip Log
Viewing the last 10 trips in the trip memory.
900 Service Information and VSD Data
Electronic type label for viewing the software version and
VSD type.
9.4 Programming during
operation
Most of the parameters can be changed during operation
without stopping the VSD. Parameters that can not be
changed are marked with a lock symbol in the display.
9.5 Editing values in a menu
Most values in the second row in a menu can be changed in
two different ways. Enumerated values like the baud rate can
only be changed with alternative 1.
Alternative 1
When you press the + or - keys to change a value, the cursor
is blinking to the left in the display and the value is increased
or decreased when you press the appropriate key. If you keep
the + or - keys pressed, the value will increase or decrease
continuously. When you keep the key pressed the change
speed will increase. The Toggle key is used to change the
sign of the entered value. The sign of the value will also
change when zero is passed. Press Enter to confirm the value.
Alternative 2
Press the + or - key to enter edit mode. Then press the Prev
or Next key to move the cursor to the right most position of
the value that should be changed. The cursor will make the
selected character blink. Move the cursor using the Prev or
Next keys. When you press the + or - keys, the character at
the cursor position will increase or decrease. This alternative
is suitable when you want to make large changes, i.e. from 2
s to 400 s.
To change the sign of the value, press the toggle key. This
makes it possible to enter negative values.
Example: When you press Next the 4 will blink.
Press Enter to save the setting and Esc to leave the edit
mode.
9.6 Copy current parameter to
all sets
When a parameter is displayed, press the Enter key for 5 sec-
onds. Now the text To all sets? is displayed. Press Enter to
copy the setting for current parameter to all sets.
NOTE: If you try to change a function during operation
that only can be changed when the motor is stopped, the
message “Stop First” is displayed.
