Emotron VFX 2.0 User Manual

Emotron AB 01-4429-01r2 Mounting 13
Fig. 15 VFX48: Model 210 to 250 (F)
VFX69: Model 90 to 175 (F69) including cable
interface for mains, motor and communication
2.3 Cabinet mounting
2.3.1 Cooling
If the variable speed drive is installed in a cabinet, the rate of
airflow supplied by the cooling fans must be taken into con-
sideration.
2.3.2 Mounting schemes
Fig. 16 VFX48: Model 300 to 500 (G and H)
VFX69: Model 210 to 375 (H69)
Table 5 Flow rates cooling fans
Frame VFX Model Flow rate [m
3
/hour]
B003-018 75
C 026 – 031 120
C 037 - 046 170
E 090 - 175 510
F 210 - 250
800
F69 090 - 175
G 300 - 375 1020
H 430 - 500
1600
H69 210 - 375
I 600 - 750
2400
I69 430 - 500
335
344,5
30
922,50
300
22.50
10
925
952,50
150
Ø16(3x)
Ø9(x6)
314
Cable dimensions 27-66 mm
J 860 - 1000
3200
J69 600 - 650
K 1200 - 1500
4800
K69 750 - 1000
NOTE: For the models 860 to 1500 the mentioned
amount of air flow should be divided equally over the two
cabinets.
Table 5 Flow rates cooling fans
Frame VFX Model Flow rate [m
3
/hour]
600
2330
600
