Emotron VFX 2.0 User Manual

12 Mounting Emotron AB 01-4429-01r2
Fig. 12 VFX40/50: Model 046 - 073 (X2)
Fig. 13 Cable interface for mains, motor and communication,
VFX40/50: Model 046 - 073 (X2).
Fig. 14 VFX48: Model 090 to 175 (E) including cable inter-
face for mains, motor and communication
10570
220
30 160
Ø 13 (2x)
Ø 7 (4x)
590
External
Interface
Glands
M20
Glands
M40
284,5
275
30
922,50
120
240
Ø9(6x)
Ø16(3)
10
22,5
952,50
314
925
Membrane cable
gland M60
