4.4 Connection example
Fig. 29 gives an overall view of a VSD connection example.
Fig. 29 Connection example
NG_06-F27
L1
L3
L1
L2
PE
1
2
3
U
V
W
DC+
R
31
32
33
41
13
21
14
20
12
21
6
7
8
9
10
18
11
15
16
17
22
19
51
52
42
43
5
4
PREV NEXT ESC
ENTER
RESET
LOC/
REM
DC -
RFI-
filter
+10 VDC
AnIn 1: Reference
AnIn 2
AnIn 3
AnIn 4
-10 VDC
Common
DigIn 1:RunL*
DigIn 2:RunR*
DigIn3
+24 VDC
Common
DigIn 4
DigIn 5
DigIn 6
DigIn 7
DigIn 8:Reset*
Common
AnOut 1
AnOut 2
DigOut 1
DigOut 2
Motor
Fieldbus option
or PC
Option board
Other options
0 - 10 V
4 - 20 mA
1
2
3
6
7
5
4
Alternative for
potentiometer control**
Optional
* Default setting
Relay 1
Relay 2
Relay 3
** The switch S1 is set to U
