Emotron VFX 2.0 User Manual

60 Functional Description Emotron AB 01-4429-01r2
11.2.3 Mains supply voltage [21B]
In this menu the nominal mains supply voltage connected to
the VSD can be selected. The setting will be valid for all
parameter sets. The default setting, Not defined, is never
selectable and is only visible until a new value is selected.
Once the supply voltage is set, this selection will not be
affected by the Load Default command [243].
Brake chopper activation level is adjusted using the setting
of [21B].
Communication information
11.2.4 Motor Data [220]
In this menu you enter the motor data to adapt the VSD to
the connected motor. This will increase the control accuracy
as well as different read-outs and analogue output signals.
Motor M1 is selected as default and motor data entered will
be valid for motor M1. If you have more than one motor
you need to select the correct motor in menu [212] before
entering motor data.
Motor Voltage [221]
Set the nominal motor voltage.
Communication information
Motor Frequency [222]
Set the nominal motor frequency.
WARNING: This menu must be set according
to the VSD product lable and the supply
voltage used. Wrong setting might damage
the VSD or brake resistor.
NOTE: The setting is affected by the Load from CP
command [245] and if loading parameter file via
EmoSoftCom.
Default: Not defined
Not Defined 0
Inverter default value used. Only valid if
this parameter is never set.
220-240 V 1 Only valid for VFX40/48
380-415 V 3 Only valid for VFX40/48/50
440-480 V 4 Only valid for VFX48/50/52
500-525 V 5 Only valid for VFX50/52/69
550-600 V 6 Only valid for VFX69
660-690 V 7 Only valid for VFX69
Modbus Instance no/DeviceNet no: 43381
Profibus slot/index 170/30
Fieldbus format UInt
Modbus format UInt
NOTE: The parameters for motor data cannot be
changed during run mode.
21B Supply Volts
Stp Not defined
A
NOTE: The default settings are for a standard 4-pole
motor according to the nominal power of the VSD.
NOTE: Parameter set cannot be changed during run if
the sets is set for different motors.
NOTE: Motor Data in the different sets M1 to M4 can be
revert to default setting in menu [243], Default>Set.
WARNING: Enter the correct motor data to
prevent dangerous situations and assure
correct control.
Default:
400 V for VFX 40 and 48
500 V for VFX 50 and 52
690 V for VFX 69
Range: 100-700 V
Resolution 1 V
NOTE: The Motor Volts value will always be stored as a 3
digit value with a resolution of 1 V.
Modbus Instance no/DeviceNet no: 43041
Profibus slot/index 168/200
Fieldbus format
Long,
1=0.1 V
Modbus format EInt
Default: 50 Hz
Range: 24-300 Hz
Resolution 1 Hz

221 Motor Volts
Stp M1: 400V
A

222 Motor Freq
Stp M1: 50Hz
A
