Emotron VFX 2.0 User Manual

142 Functional Description Emotron AB 01-4429-01r2
I/O board Status [728] - [72A]
Indicates the status for the additional I/O on option boards
1 (B1), 2 (B2) and 3 (B3).
Communication information
11.7.3 Stored values [730]
The shown values are the actual values built up over time.
Values are stored at power down and updated again at power
up.
Run Time [731]
Displays the total time that the VSD has been in the Run
Mode.
Communication information
Reset Run Time [7311]
Reset the run time counter. The stored information will be
erased and a new registration period will start.
Communication information
Mains time [732]
Displays the total time that the VSD has been connected to
the mains supply. This timer cannot be reset.
Communication information
Modbus Instance no/DeviceNet no: 31025 - 31027
Profibus slot/index 121/170 - 172
Fieldbus format UInt, bit 0=DigIn1
bit 1=DigIn2
bit 2=DigIn3
bit 8=Relay1
bit 9=Relay2
bit 10=Relay3
Modbus format
Unit: h: m: s (hours: minutes: seconds)
Range: 0h: 0m: 0s–65535h: 59m: 59s
Modbus Instance no/DeviceNet no:
31028 hours
31029 minutes
31030 seconds
Profibus slot/index
121/172
121/173
121/174
Fieldbus format UInt, 1=1h/m/s
Modbus format UInt, 1=1h/m/s
728 IO B1
Stp RE000 DI10
731 Run Time
Stp h:m:s
Default: No
No 0
Yes 1
Modbus Instance no/DeviceNet no: 7
Profibus slot/index 0/6
Fieldbus format UInt
Modbus format UInt
NOTE: After reset the setting automatically reverts to
“No”.
Unit: h: m: s (hours: minutes: seconds)
Range: 0h: 0m: 0s–65535h: 59m: 59s
Modbus Instance no/DeviceNet no:
31031 hours
31032 minutes
31033 seconds
Profibus slot/index
121/175
121/176
121/177
Fieldbus format UInt, 1=1h/m/s
Modbus format UInt, 1=1h/m/s
NOTE: At 65535 h: 59 m the counter stops. It will not
revert to 0h: 0m.
7311 Reset RunTm
Stp No
732 Mains Time
Stp h:m:s
