Emotron VFX 2.0 User Manual

144 Functional Description Emotron AB 01-4429-01r2
Communication information
Example:
Fig. 107 shows the third trip memory menu [830]: Over
temperature trip occurred after 1396 hours and 13 minutes
in Run time.
Fig. 107 Trip 3
11.8.2 Trip Messages [820] - [890]
Same information as for menu [810].
Communication information
All nine alarm lists contain the same type of data. For exam-
ple DeviceNet parameter 31101 in alarm list 1 contains the
same data information as 31151 in alarm list 2. It is possible
to read all parameters in alarm lists 2–9 by recalculating the
DeviceNet instance number into a Profibus slot/index
number. This is done in the following way:
slot no = abs((dev instance no-1)/255)
index no = (dev instance no-1) modulo 255
dev instance no = slot nox255+index no+1
Example: We want to read out the process value out from
alarm list 9. In alarm list 1 process value has the DeviceNet
instance number 31102. In alarm list 9 it has DeviceNet
instance no 31502 (see table 2 above). The corresponding
slot/index no is then:
slot no = abs((31502-1)/255)=123
index no (modulo)= the remainder of the division above =
136, calculated as: (31502-1)-123x255=136
81F 725 Analogue input status 1-2
81G 726 Analogue input status 3-4
81H 727 Analogue output status 1-2
81I 728 I/O status option board 1
81J 729 I/O status option board 2
81K 72A I/O status option board 3
81L 731 Run Time
81M 732 Mains Time
81N 733 Energy
81O 310 Process reference
Modbus Instance no/DeviceNet no: 31102 - 31135
Profibus slot/index
121/246 - 254,
122/0 - 24
Fieldbus format
Depends on parameter,
see respective parame-
ter.
Modbus format
Depends on parameter,
see respective parame-
ter.
Trip menu Copied from Description
830 Over temp
Stp 1396h:13m
Modbus Instance no/
DeviceNet no:
31151–31185
31201–31235
31251–31285
31301–31335
31351–31385
31401–31435
31451–31485
31501–31535
Trip log list
2
3
4
5
6
7
8
9
Profibus slot/index
122/40–122/74
122/90–122/124
122/140–122/174
122/190–122/224
122/240–123/18
123/35 - 123/68
123/85–123/118
123/135–123/168
Trip log list
2
3
4
5
6
7
8
9
Fieldbus format
Depends on parameter, see respec-
tive parameter.
Modbus format
Depends on parameter, see respec-
tive parameter.
