Emotron VFX 2.0 User Manual

Emotron AB 01-4429-01r2 Functional Description 143
Energy [733]
Displays the total energy consumption since the last energy
reset [7331] took place.
Communication information
Reset Energy [7331]
Resets the kWh counter. The stored information will be
erased and a new registration period will start.
Communication information
11.8 View Trip Log [800]
Main menu with parameters for viewing all the logged trip
data. In total the VSD saves the last 10 trips in the trip
memory. The trip memory refreshes on the FIFO principle
(First In, First Out). Every trip in the memory is logged on
the time of the Run Time [731] counter. At every trip, the
actual values of several parameter are stored and available for
troubleshooting.
11.8.1 Trip Message log [810]
Display the cause of the trip and what time that it occurred.
When a trip occurs the status menus are copied to the trip
message log. There are nine trip message logs [810]–[890].
When the tenth trip occurs the oldest trip will disappear.
For fieldbus integer value of trip message, see message table
for warnings, [722].
Communication information
Trip message [811]-[81N]
The information from the status menus are copied to the
trip message log when a trip occurs.
Unit: kWh
Range: 0.0–999999kWh
Modbus Instance no/DeviceNet no: 31034
Profibus slot/index 121/178
Fieldbus format Long, 1=1 W
Modbus format EInt
Default: No
Selection: No, Yes
Modbus Instance no/DeviceNet no: 6
Profibus slot/index 0/5
Fieldbus format UInt
Modbus format UInt
NOTE: After reset the setting automatically goes back to
“No”.
733 Energy
Stp kWh
7331 Rst Energy
Stp No
Unit: h: m (hours: minutes)
Range: 0h: 0m–65355h: 59m
NOTE: Bits 0–5 used for trip message value. Bits 6–15
for internal use.
Modbus Instance no/DeviceNet no: 31101
Profibus slot/index 121/245
Fieldbus format UInt
Modbus format UInt
Trip menu Copied from Description
811 711 Process Value
812 712 Speed
813 712 Torque
814 714 Shaft Power
815 715 Electrical Power
816 716 Current
817 717 Output voltage
818 718 Frequency
819 719 DC Link voltage
81A 71A Heatsink Temperature
81B 71B PT100_1, 2, 3
81C 721 VSD Status
81D 723 Digital input status
81E 724 Digital output status
8x0 Trip message
Stp h:mm:ss
810 Ext Trip
Stp 132:12:14
