Emotron VFX 2.0 User Manual

Emotron AB 01-4429-01r2 Functional Description 77
Communication Fault [264]
Main menu for communication fault/warning settings. For
further details please see the Fieldbus option manual.
Communication Fault Mode [2641]]
Selects action if a communication fault is detected.
Communication information
Communication Fault Time [2642]]
Defines the delay time for the trip/warning.
Communication information
Ethernet [265]
Settings for Ethernet module (Modbus/TCP). For further
information, see the Fieldbus option manual.
IP Address [2651]
MAC Address [2652]
Subnet Mask [2653]
Gateway [2654]
DHCP [2655]
Default: Off
Off 0 No communication supervision.
Trip 1
RS232/485 selected:
The VSD will trip if there is no communica-
tion for time set in parameter [2642].
Fieldbus selected:
The VSD will trip if:
1. The internal communication between
the control board and fieldbus option is
lost for time set in parameter [2642].
2. If a serious network error has occurred.
Warning 2
RS232/485 selected:
The VSD will give a warning if there is no
communication for time set in parameter
[2642].
Fieldbus selected:
The VSD will give a warning if:
1. The internal communication between
the control board and fieldbus option is
lost for time set in parameter [2642].
2. If a serious network error has occurred.
NOTE: Menu [214] and/or [215] must be set to COM to
activate the communication fault function.
Modbus Instance no/DeviceNet no: 43037
Profibus slot/index 168/196
Fieldbus format UInt
Modbus format UInt
Default: 0.5 s
Range: 0.1-15 s
2641 ComFlt Mode
Stp Off
A
2642 ComFlt Time
Stp 0.5s
A
Modbus Instance no/DeviceNet no: 43038
Profibus slot/index 168/197
Fieldbus format Long, 1=0.1 s
Modbus format EInt
NOTE: The Ethernet module must be re-booted to
activate the below settings. For example by toggling
parameter [261]. Non-initialized settings indicated by
flashing display text.
Default: 0.0.0.0
Default: An unique number for the Ethernet module.
Default: 0.0.0.0
Default: 0.0.0.0
Default: Off
Selection: On/Off
2651 IP Address
000.000.000.000
2652 MAC Address
Stp 000000000000
A
2653 Subnet Mask
0.000.000.000
2654 Gateway
0.000.000.000
2655 DHCP
Stp Off
A
