Emotron VFX 2.1 User Manual

104 Functional description CG Drives & Automation 01-7492-01r1
Copy All Settings to Control Panel
[244]
All the settings can be copied into the control panel
including the motor data. Start commands will be ignored
during copying.
Load Settings from Control Panel [245]
This function can load all four parameter sets from the
control panel to the AC drive. Parameter sets from the
source AC drive are copied to all parameter sets in the target
AC drive, i.e. A to A, B to B, C to C and D to D.
Start commands will be ignored during loading.
ComFlt Set [246]
This menu specifies the parameter set that should be loaded
when a communication error occurs, if the communication
fault mode is set to change parameter set (See menus [2641],
[2643] and [2647]). The digital output / relay “ComFlt Set”
is activated when a communication error changes the
parameter set.
244 Copy to CP
Default: No Copy
No Copy 0 Nothing will be copied
Copy 1 Copy all settings
NOTE: The actual value of menu [310] will not be
copied into control panel memory set.
245 Load from CP
Default: No Copy
No Copy 0 Nothing will be loaded.
A 1 Data from parameter set A is loaded.
B 2 Data from parameter set B is loaded.
C 3 Data from parameter set C is loaded.
D 4 Data from parameter set D is loaded.
ABCD 5
Data from parameter sets A, B, C and D
are loaded.
A+Mot 6
Parameter set A and Motor data are
loaded.
B+Mot 7
Parameter set B and Motor data are
loaded.
C+Mot 8
Parameter set C and Motor data are
loaded.
D+Mot 9
Parameter set D and Motor data are
loaded.
ABCD+
Mot
10
Parameter sets A, B, C, D and Motor data
are loaded.
M1 11 Data from motor 1 is loaded.
M2 12 Data from motor 2 is loaded.
M3 13 Data from motor 3 is loaded.
M4 14 Data from motor 4 is loaded.
M1M2M3
M4
15 Data from motor 1, 2, 3 and 4 are loaded.
All 16 All data is loaded from the control panel.
NOTE: Loading from the control panel will not affect
the value in menu [310].
NOTE: Menu [241] must be set to “Com” (5) for this
menu [246] to be active.
246 ComFlt Set
Default: Keep Last
A 0 Data from parameter set A is loaded.
B 1 Data from parameter set B is loaded.
C 2 Data from parameter set C is loaded.
D 3 Data from parameter set D is loaded.
DigIn 4
Parameter set is selected via a digital
input. Define which digital input in menu
[520] Digital inputs.
Keep Last 5 Do not change parameter set.
