iPAK2 User Guide
10
1.4. Programming options
1.4.1. NetFlash
This PC-compatible program displays and allows
editing of all welding parameters and status
information.
In addition to programming, NetFlash provides
backup/restore functions for control data, live data
logging to a file and a utility for updating the firmware
in the iPAK2.
1.4.2. WSP3 Pendant
iPAK2 works with the same WSP3 pendant that is used
with EN7000, iPAK and WS2003. Access to all
parameters is provided, plus diagnostic indication.
1.4.3. EtherNet/IP
On v2 models, EtherNet/IP is integrated as standard.
On other models, an optional adapter card can be
fitted to the expansion port, providing full data access
via the EtherNet/IP protocol.
1.4.4. Modbus
A PLC or HMI MODBUS master can be used to program,
control and monitor iPAK2s. All parameters are directly
mapped to MODBUS registers for easy access. Both
MODBUS-TCP/IP (Ethernet) and MODBUS-RTU (RS485)
protocols are supported.
