Entron iPAK2

iPAK2 User Guide
16
2.2. Program options
Each weld program has a number of optional features.
Parameter Range Description
Pre-heat on/off Enables or disables the Pre-heat parameters
Post-heat
2
on/off Enables or disables the Post-heat parameters
Pulsations 1 - 99 The number of times the Main heat – Cool2 interval is repeated
Link
2
on/off The next welding program will be started automatically if the
input signals are maintained
Repeat on/off The welding program will be repeated if the input signals are
maintained
Force profile on/off Use multiple force values during the weld
Inhibit
1
on/off An inhibited program will not run
C-Monitor shunt
2
on/off The measured conduction will be checked against the C-Monitor
shunt limit
C-Monitor wear
2
on/off The measured conduction will be checked against the C-Monitor
wear limit
Retry
2
On/off Weld schedule will re-run if a Low Main Current is detected – spot
welds only.
1
If an inhibited program is not linked then attempting to run it will produce an error message. If
the program is linked, then the program will be skipped and the next linked program will run.
This feature may be used to temporarily disable a program in a cascade.
2
Extended mode must be set in Configuration to use this feature
Pulsations can be used to temper the material, control nugget
growth and reduce electrode wear.
The START signal must be maintained for the full duration of the
sequence if pulsations are set to 10 or more, otherwise the
sequence will terminate after 10 pulses.
