Entron iPAK2

iPAK2 User Guide
54
6.4.3. Calibration parameters
Variable Channel Address
offset
Type Description
Calibration %IW0 WORD
ARRAY
[0..63]
Ip max Calibration [0] %IW0 WORD 0 – inverter specific
A out X1 Calibration [1] %IW1 WORD 0 – 10000 mV
A out Y1 Calibration [2] %IW2 WORD 0 – 32767
A out X2 Calibration [3] %IW3 WORD 0 – 10000 mV
A out Y2 Calibration [4] %IW4 WORD 0 – 32767
A in X1 Calibration [5] %IW5 WORD 0 – 10000 mV
A in Y1 Calibration [6] %IW6 WORD 0 – 32767
A in X2 Calibration [7] %IW7 WORD 0 – 10000 mV
A in Y2 Calibration [8] %IW8 WORD 0 – 32767
Reserved Calibration [9] %IW9 WORD
Toroid sensitivity Calibration [10] %IW10 WORD 1 – 60000 mV/kA
Convert CT Calibration [11] %IW11 WORD 0 = use 2-points
1 = use turns ratio
CT X1 Calibration [12] %IW12 DWORD 0 – 32000
CT Y1 Calibration [14] %IW14 DWORD 0 – 500000
CT X2 Calibration [16] %IW16 DWORD 0 – 32000
CT Y2 Calibration [18] %IW18 DWORD 0 – 500000
CT max Calibration [20] %IW20 DWORD Read only
Turns ratio Calibration [22] %IW22 WORD 1 – 999
Reserved Calibration [23] %IW23 WORD
CCC X1 Calibration [24] %IW24 WORD 0 – 999
CCC Y1 Calibration [25] %IW25 DWORD 0 – 500000
CCC X2 Calibration [27] %IW27 WORD 0 – 999
CCC Y2 Calibration [28] %IW28 DWORD 0 – 500000
Toroid factor Calibration [30] %IW30 WORD 1 – 10
Blanking Calibration[31] %IW31 WORD 0 – 99 ms
Reserved Calibration[32]-[63]
