6.4.2. Electrode parameters
Variable Channel Address
offset
Type Description
Electrode %IW0 WORD
ARRAY
[0..63]
Attributes Electrode [0] %IW0 WORD
Enable counter Bit 0 %IX0.0 BOOL 0 = off, 1 = on
Enable tipdress Bit 1 %IX0.1 BOOL 0 = off, 1 = on
Enable stepper Bit 2 %IX0.2 BOOL 0 = off, 1 = on
Stop at endcount Bit 3 %IX0.3 BOOL 0 = off, 1 = on
Stop at endstep Bit 4 %IX0.4 BOOL 0 = off, 1 = on
Transformer Electrode [1] %IW1 WORD 0 – 7
Counter Electrode [2] %IW2 WORD 0 – 9999
Endcount Electrode [3] %IW3 WORD 0 – 9999
Dressings done Electrode [4] %IW4 WORD 0 – 9999
Max dressings Electrode [5] %IW5 WORD 0 – 9999
Stepper spots done Electrode [6] %IW6 DWORD Read only
Stepper % done Electrode [8] %IW8 WORD Read only
Stepper reset to Electrode [9] %IW9 WORD 0 – 9999
Stepper spots Electrode
[10..19]
%IW10..19 WORD 0 – 9999
Stepper delta H Electrode
[20..29]
%IW20..29 WORD 0 – 500 (% x 10)
Stepper delta I Electrode
[30..39]
%IW30..39 WORD 0 – 500 (% x 10)
Reserved Electrode
[40]-[63]
