12.2.1. Keypad
Return to the previous screen or
move between menu screens.
Select a different function or
parameter. The selected function or
parameter will flash and the visible
window will scroll if required.
Return. Access the selected
function.
Alter the selected parameter. Press
both keys together to set the
parameter to 0 or to its minimum
value.
12.2.2. Diagnostic or Status screen
Status message
Ready 
Measured Pre-current
|‐‐0Aprog7
Program used
Measured Main current
‐|‐11.7kA5.66kN
Measured force
Measured Post-current
‐‐|0A~30.5%
Measured pulse width
Tip: When editing parameters, you can quickly switch to the diagnostic screen by
pressing the Return key, then switch back again by pressing F.
