6.4.4. Configuration parameters
Variable Channel Addres
s offset
Type Description
Configuration %IW0 WORD
ARRAY
[0..63]
Weld type Configuration[0] %IW0 WORD 0 = spot
1 = seam
Second stage Configuration[1] %IW1 WORD
Bit 0
Bit 1
%IX1.0
%IX1.1
BOOL
BOOL
00 = none
01 =before Squeeze
10 = after Squeeze
Bit 2 %IX1.2 BOOL Reserved
Bit 3 %IX1.3 BOOL 0 = check first
program
1 = check every
program
Retract Configuration[2] %IW2 WORD 0 = simple
1 = hilift plus
2 = hilift minus
3 = maintained
Measure Configuration[3] %IW3 WORD 0 = primary
1 = secondary
Ip limit Configuration[4] %IW4 WORD 0 – inverter specific
Units Configuration[5] %IW5 WORD 0 = metric
1 = imperial
Electrodes Configuration[6] %IW6 WORD 0 = single, 1 = multi
Fault Configuration[7] %IW7 WORD
Stop Bit 0 %IX7.0 BOOL 1 = stop on fault
EOS Bit 1 %IX7.1 BOOL 1 = EOS on fault
Headlock Bit 2 %IX7.2 BOOL 1 = headlock on
fault
iPAK(v1) Bit 3 %IX7.3 BOOL 1 = use NOT READY
sense
Contactor Configuration[8] %IW8 WORD 1 - 99 seconds
0 = off
Program select Configuration[9] %IW9 WORD 0 = external
1 = internal
Internal prog Configuration[10] %IW10 WORD 0 - 255
I/O source Configuration[11] %IW11 WORD 0 = discrete
1 = MODBUS COM0
2 = MODBUS COM1
3 = MODBUS COM2
4 = n/a
5 = MODBUS COM4
6 = MODBUS COM5
7 = EtherNet/IP
COM7
Regulation Configuration[12] %IW12 WORD 0 = primary
1 = secondary
COM2 address Configuration[13] %IW13 WORD 1 - 247
COM2 baud rate Configuration[14] %IW14 WORD 0 = 9600
1 = 19200
2 = 38400
3 = 57600
Bus Monitor Configuration[15] %IW15 WORD 0 = iPAK(v1) inverter
1 = iPAKv2 inverter
