Entron iPAK2

iPAK2 User Guide
56
Adapter code Configuration[16] %IW16 WORD
Analog output
function
Configuration[17] %IW17 WORD 0 = force
1 = waveform
Analog output
scale (10 V =)
Configuration[18] %IW18 DWORD 0 – 500 kA
Security
2
Configuration[20] %IW20 WORD 0 = off
1 = key-switch
2 = PIN on WSP3
Security timeout
2
Configuration[21] %IW21 WORD 0 – 10 minutes
Security PIN0
2
Configuration[22] %IW22 WORD 1000 - 9999
Security PIN1
2
Configuration[23] %IW23 WORD 1000 - 9999
Security PIN2
2
Configuration[24] %IW24 WORD 1000 - 9999
Security PIN3
2
Configuration[25] %IW25 WORD 1000 - 9999
Security PIN4
2
Configuration[26] %IW26 WORD 1000 - 9999
IP address (msb)
1
Configuration[27] %IW27 WORD 0 - 255
IP address
1
Configuration[28]
%IW28 WORD 0 - 255
IP address
1
Configuration[29] %IW29 WORD 0 - 255
IP address (lsb)
1
Configuration[30] %IW30 WORD 0 - 255
Sub-net
mask(msb)
1
Configuration[31]
%IW31 WORD 0 - 255
Sub-net mask
1
Configuration[32] %IW32 WORD 0 - 255
Sub-net mask
1
Configuration[33] %IW33 WORD 0 - 255
Sub-net mask (lsb) Configuration[34] %IW34 WORD 0 - 255
Gateway (msb)
1
Configuration[35] %IW35 WORD 0 - 255
Gateway
1
Configuration[36] %IW36 WORD 0 - 255
Gateway
1
Configuration[37] %IW37 WORD 0 - 255
Gateway (lsb)
1
Configuration[38] %IW38 WORD 0 - 255
Features Configuration[39] %IW39 WORD 0 = standard
1 = extended
Toroid test Configuration[40] %IW40 WORD 0 = off, 1 = on
Analog control Configuration[41] %lW41 WORD 0 = off, 1 = on
Reserved Configuration
[42]-[63]
1
Applies to COM4, COM5 and COM6 only.
2
Not accessible on WSP3.
