Entron iPAK2

iPAK2 User Guide
44
6.2. Inputs to iPAK2
Variable Channel Address Type Description
Write inputs %QW0 WORD
ARRAY
[0..1]
Write multiple registers
Write inputs [0] %QW0 WORD WRITE 16#8000 (= 32768)
Start Bit 0 %QX0.0 BOOL
Weld on Bit 1 %QX0.1 BOOL
Stop Bit 2 %QX0.2 BOOL
Transformer thermal Bit 3 %QX0.3 BOOL
2
nd
stage Bit 4 %QX0.4 BOOL
Retract Bit 5 %QX0.5 BOOL
Reset fault Bit 6 %QX0.6 BOOL
Reset counter Bit 7 %QX0.7 BOOL
Reset stepper Bit 8 %QX1.0 BOOL
Reserved Bit 9 %QX1.1 BOOL
Reserved Bit 10 %QX1.2 BOOL
Reserved Bit 11 %QX1.3 BOOL
Reserved Bit 12 %QX1.4 BOOL
Reserved Bit 13 %QX1.5 BOOL
Reserved Bit 14 %QX1.6 BOOL
Reserved Bit 15 %QX1.7 BOOL
Write inputs [1] %QW2 WORD WRITE 16#8001 (= 32769)
P1 Bit 0 %QX2.0 BOOL
P2 Bit 1 %QX2.1 BOOL
P4 Bit 2 %QX2.2 BOOL
P8 Bit 3 %QX2.3 BOOL
P16 Bit 4 %QX2.4 BOOL
P32 Bit 5 %QX2.5 BOOL
P64 Bit 6 %QX2.6 BOOL
P128 Bit 7 %QX2.7 BOOL
Reserved Bit 8 %QX3.0 BOOL
Reserved Bit 9 %QX3.1 BOOL
Reserved Bit 10 %QX3.2 BOOL
Reserved Bit 11 %QX3.3 BOOL
Reserved Bit 12 %QX3.4 BOOL
Reserved Bit 13 %QX3.5 BOOL
Reserved Bit 14 %QX3.6 BOOL
Reserved Bit 15 %QX3.7 BOOL
