2.6. Valve control
iPAK2 has eight discrete outputs (AV1 – AV8) that can be operated independently during a weld
sequence. The valves are categorised as WAV, MOTOR
1
or AUX valves.
 A WAV valve turns on at start of sequence and turns off at the end of the Hold interval.
 A MOTOR valve turns on after the 2
nd
stage test (see Configuration section), and turns
off at the start of the Hold interval.
 An AUX valve may be programmed to come on during any interval of the weld
sequence, including the Off time in repeat or roll-spot mode.
iPAK2 features
parameter
Configuration WAV
function
MOTOR
function
Description
Standard All AV1 n/a AV1 is automatically selected
Extended (spot)
Single electrode AV1 n/a AV1 is automatically selected
Multi-electrode AV1 – AV8 n/a
Any combination of AV1 to
AV8 may be selected
Extended
(seam)
Single electrode AV1 AV2
AV1 and AV2 are
automatically selected
Multi-electrode AV1 – AV8 AV1 – AV8
Any combination of AV1 to
AV8 may be selected
Valves not being used for the WAV or MOTOR function may be used as AUX valves.
WAV/MOTOR settings always override any corresponding AUX settings.
The weld programs contain the following valve control parameters.
Parameter Units Range Description
WAV AV1 – AV8 WAV output
Motor
1
AV1 – AV8 Motor output
Squeeze AV1 – AV8 on/off Valve states during the Squeeze interval
Pre-heat AV1 – AV8 on/off Valve states during the Pre-heat interval
Cool1 AV1 – AV8 on/off Valve states during the Cool1 interval
Upslope AV1 – AV8 on/off Valve states during the Upslope interval
Main heat AV1 – AV8 on/off Valve states during the Main heat interval
Cool2 AV1 – AV8 on/off Valve states during the Cool2 interval
Downslope AV1 – AV8 on/off Valve states during the Downslope interval
Post-heat AV1 – AV8 on/off Valve states during the Post-heat interval
Hold AV1 – AV8 on/off Valve states during the Hold interval
Off
2
AV1 – AV8 on/off Valve states during the Off interval
1
Seam mode only.
2
Repeat mode or Roll-Spot program option must be enabled to use this feature.
