4.5. Force calibration
The analog input and analog output can be used for force control in terms of kN or lbf when
they have been calibrated.
Parameter Units Range Description
OUT Point 1 mV 0 - 10000 Analog output (point 1)
OUT Point 1 kN/lbf Measured output force (point 1)
OUT Point 2 mV 0 - 10000 Analog output (point 2)
OUT Point 2 kN/lbf Measured output force (point 2)
IN Point 1 mV 0 - 10000 Analog input (point 1)
IN Point 1 kN/lbf Measured input force (point 1)
IN Point 2 mV 0 - 10000 Analog input (point 2)
IN Point 2 kN/lbf Measured input force (point 2)
The relationship between the analog input and output and the electrode force can be
determined by measuring the values at two points. The values define a linear relationship
between mV and kN/lbf.
The force can be independently calibrated for each electrode.
