5.5. Discrete interface
24V DC only. Do not connect to 110V AC!
5.5.1. Inputs
Current sinking. Connect input to 24V DC to activate.
Input P1 pin
Stop 3
Thermal 4
Weld on 5
5.5.2. Outputs
Current sourcing. Connect load between output and 0V.
Output P3 pin
AV1 1
AV2 2
AV3 3
HAV 4
Counter /
tip dress request
6
Stepper 7
Pre-warn 8
AV4 9
AV5 10
AV6 11
AV7 12
AV8 13
EOS 14
Fault 15
Ready 16
Contactor 17
0V (SVC) 18
Input P2 pin
24 VDC output 1
Start 2
P1 6
P2 7
P4 8
P8 9
P16 10
P32 11
Reset stepper 12
Reset counter /
tip dress acknowledge
13
Retract 14
Reset fault 15
2
nd
stage 16
P64 / Edit enable 17
