Cool2 force Weld
program [40]
%IW40 WORD 0 – 32767
2
Downslope force Weld
program [41]
%IW41 WORD 0 – 32767
2
Post-heat force Weld
program [42]
%IW42 WORD 0 – 32767
2
Hold force Weld
program [43]
%IW43 WORD 0 – 32767
2
Off force Weld
program [44]
%IW44 WORD 0 – 32767
2
Force low limit Weld
program [45]
%IW45 WORD 0 – 99
Force high limit Weld
program [46]
%IW46 WORD 0 – 99
Selected WAV Weld
program [47]
%IW47 WORD 0 – 7
Current low limit Weld
program [48]
%IW48 WORD 0 – 99
Current high limit Weld
program [49]
%IW49 WORD 0 – 99
Selected electrode Weld
program [50]
%IW50 WORD 0 – 7
Linked program Weld
program [51]
%IW51 WORD 0 – 255
Reserved Weld
program [52]
%IW52 WORD
Reserved Weld
program [53]
%IW53 WORD
Reserved Weld
program [54]
%IW54 WORD
Reserved Weld
program [55]
%IW55 WORD
Reserved Weld
program [56]
%IW56 WORD
Reserved Weld
program [57]
%IW57 WORD
C-Monitor
Shunt limit
Weld
program [58]
%IW58 WORD 0 – 99 %
C-Monitor
Wear limit
Weld
program [59]
%IW59 WORD 0 – 99 %
Reserved Weld
program [60]
%IW60 WORD
Attributes2 Weld
program [61]
%IW61 WORD
Inhibited Bit 0 %IX61.0 BOOL 0 = enable,1 = inhibit
C-Monitor
Shunt enable
Bit 1 %IX61.1 BOOL 0 = off, 1 = on
C-Monitor
Wear enable
Bit 2 %IX61.2 BOOL 0 = off, 1 = on
Retry enable Bit 3 %IX61.3 BOOL 0 = off, 1 = on
Motor valves
1
Weld
program [62]
%IW62 WORD
Reserved Weld
program [63]
%IW63 WORD
2
Divide value by 898.99 for kN. Divide value by 4 for lbf.
