Entron iPAK2

iPAK2 User Guide
51
Reserved) Weld
program [18]
%IW18 WORD
Post-current Weld
program [19]
%IW19 DWORD 0 – 500000
Hold time Weld
program [21]
%IW21 WORD 0 – 1999
Off time Weld
program [22]
%IW22 WORD 0 – 1999
Upslope time Weld
program [23]
%IW23 WORD 0 – 1999
Downslope time Weld
program [24]
%IW24 WORD 0 – 1999
Squeeze valves
1
Weld
program [25]
%IW25 WORD
Pre-heat valves
1
Weld
program [26]
%IW26 WORD
Cool1 valves
1
Weld
program [27]
%IW27 WORD
Upslope valves
1
Weld
program [28]
%IW28 WORD
Main heat valves
1
Weld
program [29]
%IW29 WORD
Cool2 valves
1
Weld
program [30]
%IW30 WORD
Downslope valves
1
Weld
program [31]
%IW31 WORD
Post-heat valves
1
Weld
program [32]
%IW32 WORD
Hold valves
1
Weld
program [33]
%IW33 WORD
Off valves
1
Weld
program [34]
%IW34 WORD
1
Weld
program [nn]
%IXnn.0.0 BOOL AV1 state 1 = ON
Weld
program [nn]
%IXnn.0.1 BOOL AV2 state 1 = ON
Weld
program [nn]
%IXnn.0.2 BOOL AV3 state 1 = ON
Weld
program [nn]
%IXnn.0.3 BOOL AV4 state 1 = ON
Weld
program [nn]
%IXnn.0.4 BOOL AV5 state 1 = ON
Weld
program [nn]
%IXnn.0.5 BOOL AV6 state 1 = ON
Weld
program [nn]
%IXnn.0.6 BOOL AV7 state 1 = ON
Weld
program [nn]
%IXnn.0.7 BOOL AV8 state 1 = ON
Squeeze force Weld
program [35]
%IW35 WORD 0 – 32767
2
Pre-heat force Weld
program [36]
%IW36 WORD 0 – 32767
2
Cool1 force Weld
program [37]
%IW37 WORD 0 – 32767
2
Upslope force Weld
program [38]
%IW38 WORD 0 – 32767
2
Main heat force Weld
program [39]
%IW39 WORD 0 – 32767
2
