iPAK2 User Guide
29
Example: the diagram below shows how the electrodes can be assigned to transformers/SCRs
Electrodes 0 and 1 are assigned to transformer/SCR 0
T0
Electrodes 2 and 3 are assigned to transformer/SCR 1
T1
Electrodes 4, 5 and 6 are assigned to transformer/SCR 2
T2
Electrode 7 is assigned to transformer/SCR 3
T3
E2
E3
E4 E6
E5
E7
E0
E1
