The operation is similar when the programs are linked together in multi-gun cascade mode:
The program select inputs select the first program in the cascade (0 in this example).
Start input
EOS output
AV1 output
AV2 output
AV3 output
AV4 output
Program
First
program #
select
Current
( Program 0)
Current
( Program 1)
Current
( Program 2)
Current
( Program 3)
