For example:
Electrode Transformer Description
0 0
Electrodes 0, 1 and 2 are assigned to transformer 0
1 0
2 0
3 1
Electrodes 3 and 4 are assigned to transformer 1
4 1
5 2 Electrode 5 is assigned to transformer 2
6 3
Electrodes 6 and 7 are assigned to transformer 3
7 3
The electrodes can then be assigned to weld programs:
Weld program Electrode Description
0 0
Weld programs 0 and 1 are assigned to Electrode 0
1 0
2 1
Weld programs 2 and 3 are assigned to Electrode 1
3 1
4 2
Weld programs 4 and 5 are assigned to Electrode 2
5 2
6 3
Weld programs 6 and 7 are assigned to Electrode 3
7 3
8 4
Weld programs 8 and 9 are assigned to Electrode 4
9 4
10 5
Weld programs 10 and 11 are assigned to Electrode 5
11 5
12 6
Weld programs 12 and 13 are assigned to Electrode 6
13 6
14 7
Weld programs 14 and 15 are assigned to Electrode 7
15 7
By implication the transformers are used as follows:
Transformer Weld
programs
Description
0 0, 1, 2, 3,
4, 5
Transformer 0 is used by weld programs 0, 1, 2, 3, 4, and
5
1 6, 7, 8, 9 Transformer 1 is used by weld programs 6, 7, 8 and 9
2 10, 11 Transformer 2 is used by weld programs 10 and 11
3 12, 13,
14,15
Transformer 3 is used by weld programs 12, 13, 14 and
15
