TROUBLESHOOTING Engine-related Trouble FIP 101
Confidential
FIP 1-19 Install Fuser
 Possible parts that caused the error
 Troubleshooting
FIP 1-20 TonerCart Error Yellow(Y)
 Possible parts that caused the error
 Troubleshooting
 FUSER UNIT
 HARNESS ASSY FUSER
 PWBA MCU
Step Check Yes No
1
Check after turning the power OFF and ON
Does the error recur even when the power is
turned off and back on again?
Go to Step [2]. End of procedure
2
Check the installation of the FUSER UNIT
Is the FUSER UNIT installed correctly?
Go to Step [3]. Reinstall the
USER ASSY
correctly.
3
Check the connection of the FUSER UNIT
Check the connection state between FUSER
UNIT and PWBA MCU.
Are P/J171 and P/J17 connected correctly?
Go to Step [4]. Reconnect the
P/J171 and P/J17
correctly.
4
Check the continuity of the HARNESS ASSY
FUSER
Is the continuity between P/J171 <=> P/J17
normal ?
Go to Step [5]. Replace the
HARNESS
ASSY FUSER.
5
Check the resistance value of the Temp.
Sensor in the FUSER UNIT
Measure the resistance value of the connectors
listed below.
 J171-8PIN <=> J171-7PIN
 J171-4PIN <=> J171-6PIN
 J171-4PIN <=> J171-5PIN
Can the resistance value be measured?
Replace the
PWBA MCU.
(p.343)
Replace the
FUSER UNIT.
(p.298)
 IMAGING CARTRIDGE (Y)
 CONNECTOR CRUM
(CRUM SENSOR) (Y)
 HARNESS ASSY CRUM
 PWBA MCU
Step Check Yes No
1
Check the installation of the IMAGING
CARTRIDGE (Y)
Is the IMAGING CARTRIDGE (Y) installed
correctly?
Go to Step [2]. Reinstall the
IMAGING
CARTRIDGE
(Y) correctly.
2
Check the installation of the CONNECTOR
CRUM (CRUM SENSOR) (Y)
Is the CONNECTOR CRUM (CRUM
SENSOR) (Y) installed correctly?
Go to Step [3]. Reinstall the
CONNECTOR
CRUM (CRUM
SENSOR) (Y)
correctly.
3
Check the connection of the CONNECTOR
CRUM (CRUM SENSOR) (Y)
Check the connection state between
CONNECTOR CRUM (CRUM SENSOR) (Y)
and PWBA MCU.
Are P/J311 and P/J31 connected correctly?
Go to Step [4]. Reconnect P/J311
and P/J31
correctly.
4
Check the continuity of the HARNESS ASSY
CRUM
Is the continuity between P/J311 <=> P/J31
normal ?
Go to Step [5]. Replace the
HARNESS
ASSY CRUM.
5
Check the CONNECTOR CRUM (CRUM
SENSOR) (Y)
Is there any damage to the CONNECTOR
CRUM (CRUM SENSOR) (Y)?
Go to Step [6]. Replace the
CONNECTOR
CRUM (CRUM
SENSOR) (Y).
(p.280)
6
Check after replacing the IMAGING
CARTRIDGE (Y)
Replace the IMAGING CARTRIDGE (Y) with
a new one. (p.271)
Does the error still occur after the replacement?
Replace the
PWBA MCU.
(p.343)
End of procedure
